Yaesu FTM-200DR 50W C4FM-FM Dual Band Digital Transceiver

Yaesu FTM-200DR 50W C4FM-FM Dual Band Digital Transceiver is a multi-functional mobile radio with a single receiver and the flexibility of a detachable front panel that may be mounted in any ideal operating position. The FTM-200DR supports optional Bluetooth wireless operation using the SSM-BT10 headset or other commercially available Bluetooth headsets with the optional BU-4 Bluetooth unit (sold separately). This 144-148 MHz and 430-450 MHz Amateur transceiver delivers reliable 50 watts of transmit performance with a heavy-duty heat sink that features FACC (Funnel AirConvection Conductor) to help keep things cool. The 2-in. high-resolution QVGA Full-Color TFT display provides high-visibility and highlights the frequency of the operating band with selectable colors: White, Blue or Red. The speaker delivers clear and crisp 3 watts of receive audio, specifically tuned for radio communications.

The new FTM-200DR comes packed with popular C4FM digital communication features like Automatic Mode Select (AMS), Digital Group ID (DG-ID) operation, Smart Navigation Functions, and the Worldwide WIRES-X Internet Communication. Set up a Fixed Node using an optional HRI200, or a Portable Digital Node with the optional SCU-40 cable kit (both sold separately).

Quickly recall a list of frequently used functions by simply pressing the [F Menu] key with the New Custom Function List (CFL) feature. The Custom Function List (CFL) will display 10 functions by default, with the ability to choose up to 8 customizable functions from any of the 124 items on the setup menu.

The Yaesu PMG (Primary Memory Group) function in the FTM-200DR allows PMG-SR Monitor (Primary Memory Group with a Single Receiver). The display frequency can register up to 5 PMG channels, regardless of the VFO or memory channel operation, and features an auto or manual mode selection. Assign 16-character alpha-numeric tags to the 1104 memory channels and automatically categorize memory channels in each band, ALL, AIR, VHF, UHF and other with the MAG (Memory Auto Grouping) function.

FTM-200DR additional features include:

* Wide range 108MHz to 999.995MHz receive coverage (480 – 999.995MHz USA Cellular Blocked)
* High-speed band scope (displays receive status of up to 61 channels or up to 21 channels in memory mode)
* VFO band skip function
* High-precision 66 channel GPS receiver and external GPS device connectivity
* 1200/9600bps APRS® Data Communication
* VOX function
* Voice recording function for receive and transmit audio
* Snapshot feature with optional MH-85A11U microphone (not included)
* microSD card slot (up to 32GB)

FTM-200DR supplied accessories:

* SSM-85D DTMF microphone
* Radio mounting bracket
* Controller bracket
* Control cable for operation with the front panel mounted
* Control cable 10 ft. (3m) for operation with the front panel detached
* USB cable
* DC power adapter
* Operating manual

The new FTM-200DR is a C4FM Digital multi-functional transceiver with a single receiver. The FTM-200DR delivers reliable and stable 50W transmit performance. The heavy-duty heat sink is equipped with FACC (Funnel Air[1]Convection Conductor). The speaker delivers 3W of clear and crisp receive audio which has been specifically tuned for radio communication. 2-inch Full-color display provides high visibility and highlights the frequency of the operating band with selectable color – White, Blue or Red. Front panel of the FTM-200DR is detachable and can be mounted at the most desirable operating position. The new FTM-200DR supports optional Bluetooth® wireless operation using the SSM-BT10 Headset or a commercially available Bluetooth® headset*.

YAESU PMG (Primary Memory Group) function in the FTM-200DR allows PMG-SR Monitor (Primary Memory Group with a Single Receiver). The display frequency can register up to 5 PMG channels, regardless of the VFO or Memory channel operation. AUTO or MANUAL mode can be selected**.

1104 Memory channels can be programmed with 16-character alpha-numeric tags. The MAG (Memory Auto Grouping) function allows memory channels to be automatically categorized in each band, ALL, AIR, VHF, UHF and OTHER.

The C4FM digital communication features which are already popular in the market, such as Automatic Mode Select (AMS), Digital Group ID (DG-ID) operation, and Smart Navigation Function are available with the new FTM[1]200DR. The FTM-200DR supports the Worldwide WIRES-X Internet Communication. A Fixed Node using an HRI[1]200, or a Portable Digital Node can be easily set up with the optional SCU-40 cable kit.

New Custom Function List (CFL) of the FTM-200DR quickly recalls a list of frequently used functions by simply pressing the [F Menu] key. 10 functions are listed by default, and up to 8 functions can be customized from the 124 items of the setup menu.

Some additional features of the FTM-200DR are:

• • Wide-range 108MHz to 999.995MHz receive coverage
  • High speed Band Scope (displays the receive status of up to 61 channels centered on the current VFO frequency or up to 21 channels in Memory Mode)
  • VFO Band Skip Function
  • High-precision 66 channel GPS Receiver
  • 1200/9600bps APRS® Data Communication
  • VOX function
  • Recording Function
  • Snapshot Feature (with MH-85A11U)
  • microSD Card Slot.
