Description

Features

> 12/24V Monitor & Camera

> 1, 2, 3, 4 View

> IP69K Waterproof & Dustproof Camera

> DVR Recording

> 2.4GHz Wireless

Specifications

Video Decoding NTSC & PAL
Cameras Supported Up to 4 Cameras
Resolution 1280 x 1024
Contrast 500:01:00
Brightness 500cd/m2
Display Settings Adjustable for each Individual Camera
Multiple Viewing Options Single/Split Screen/Quad
Reversing Guidelines Selectable On/Off
Operating Frequency 2400-2483.5MHz
Time Delay 25ms
Recording Media Micro SD Card
Max SD Card Capacity 128GB (not included)
Cycled Recording 1~4 Channels
Operating Voltage 10-36V DC
Current Consumption <500mA
Operating Temperature -20°C ~ +70°C
Storage Temperature -30°C ~ +80°C
Camera
Image Sensor 1/2.7″ inch Starlight HD
Picture Element 250,000 pixels
Viewing Angle 170° Diagonal, 127° Horizontal
Resolution 1000 TV lines
Signal Type PAL
IP Rating IP69K
Minimum Illuination 0.5 lux
Operating Voltage 10V-36V DC
Operating Frequency 2400-2483.5MHz
Transmitter Power 18dbm
Operating Temperature -20°C ~ +70°C (RH 95% Max)
Storage Temperature -30°C ~ +80°C (RH 95% Max)
Dimensions
Monitor (Excluding Mount & Sunvisor) W 185mm x H 118mm x D 35mm
Monitor (Including Mount & Sunvisor) W 200mm x H 135mm x D 75mm
Camera (Excluding Mount) W 100mm x H 50mm x D 70mm
Includes
Monitor, Camera, Sunshade, U-Bracketr, Power Cables, Antennas
Others
Shipping Weight 1.45kg
Shipping Dimensions(mm) 300 x 240 x 90
Warranty 2 Years
